SPEC SHEET
- 10' Lift
- 8. Ton LA008-10U, 1.6 Ton LA016-10U
- Dual rated with more choices of capacity
- Hook blocks are bolted, allowing easy disassembly for complete hook inspection
- Lightweight and durable all steel construction with powder coated finish and plated external components to resist corrosion
- Premium US Made Grade 80 Zinc plated alloy load chain
- Self-adjusting double pawl disk type mechanical load brake ensures positive load control
- Horseshoe chain guard allows operation in any orientation
- Optional Overload Protection is a one directional clutch that will only slip in the lift direction
- Meets: ASME/ANSI B3O.21, OSHA, NASA-STD-8719.9
- ATEX rated
II 3 GD c IIB 54º C X for limited use in Hazardous Environments - Long-life fused brake friction disk will not crack, shatter, or absorb moisture
Dual Rated
| US Ton | Metric ton |
|---|---|
| 3/4T | 0.8t |
| 1T | 1.0t |
| 1 3/4T | 1.6t |
| 2 1/4T | 2.0t |
| 2 3/4T | 2.5t |
| 3 1/2T | 3.2t |
| 7T | 6.3t |
| 10T | 9.0t |
